50mm Brushless DC Motor – 100mm Length, High Torque, Heavy-Duty BLDC for Robotics & Automation
50mm Brushless DC Motor – 100mm Length, Up to 3.0 Nm Peak Torque, Heavy-Duty Design High-power BLDC motor delivering up to 3.0 Nm peak torque with no-load speeds from 1,000 to 5,000 RPM. Available in 24V and 48V windings with conventional or slotless stator construction. Integrated Hall sensors for precise speed control. Double-shielded ball bearings for high load capacity. Ideal for collaborative robots, medical rehabilitation equipment, industrial automation, and heavy-duty actuation. IP54/... -
35mm Brushless DC Motor – 60mm Length, High Power Density BLDC with Hall Sensors
The M35-60-BLDC series is a 35mm diameter brushless DC motor with a 60mm body length, engineered for applications requiring a compact yet powerful drive solution with excellent power density. This motor platform fills the gap between 32mm and 36mm frames, delivering higher torque output than 32mm motors while maintaining a smaller footprint than 40mm frames. The combination of 35mm diameter and 60mm length makes it an ideal choice for robotics, medical equipment, industrial automation, and consumer appliances where space and performance are both critical.
The M35-60-BLDC delivers rated torque from 0.18 to 0.38 Nm depending on winding selection, with peak torque up to 1.0 Nm. No-load speeds range from 2,000 to 9,000 RPM, providing flexibility for applications requiring either high-speed operation or higher torque. The brushless design provides high efficiency (up to 87%), reducing heat generation and improving energy economy compared to brushed alternatives.
Unlike traditional brushed DC motors that require periodic brush replacement and suffer from electrical arcing, the brushless design eliminates mechanical commutation entirely. Typical operational life reaches 20,000+ hours—four times longer than equivalent brushed motors. The absence of brushes also eliminates electrical arcing, reducing EMI and making the motor suitable for sensitive medical and electronic environments. Low cogging torque design ensures smooth rotation even at very low speeds, critical for precision positioning applications.
Three integrated Hall-effect sensors provide commutation feedback for electronic speed controllers (ESC) and enable precise speed control, direction changes, and smooth starting from zero speed. The Hall sensors allow the motor to start reliably under load and maintain stable operation across a wide speed range. For closed-loop speed or position control, an optional magnetic or optical encoder (up to 2,048 PPR) can be added to the motor rear shaft.
The 60mm body length provides adequate surface area for passive heat dissipation in most applications. Double-shielded ball bearings on both ends ensure low friction and long service life even under continuous duty. Dynamic balancing of the rotor assembly minimizes vibration, important for precision applications such as surgical robots and camera gimbals. The housing can be specified with IP54 protection for dusty or humid environments. Insulation is Class F (155°C) as standard.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (6mm, 8mm, or 10mm), shaft length, and end configurations including flat, keyway, or D-cut. Gearbox attachments (planetary or spur) with reduction ratios from 3:1 to 100:1 are available for torque multiplication. Custom lead wire length and connector terminations (Molex, JST, or custom) are supported. Encoder integration and IP54 sealing are available for volume orders.
Each M35-60-BLDC motor undergoes 100% final inspection including no-load speed, no-load current, Hall sensor functionality, insulation resistance, dielectric strength, and vibration testing. Production follows ISO 9001:2015 quality management processes. RoHS and REACH compliance documentation is available. Sample motors with matched electronic speed controllers are available for engineering evaluation.
-
28mm Brushless DC Motor – 63mm Length, Extended Body, High Torque Density BLDC with Hall Sensors
The M28-63-BLDC series is a 28mm diameter brushless DC motor with an extended 63mm body length, engineered for applications requiring higher torque output than standard 28mm motors while maintaining a compact 28mm frame diameter. This motor platform fills the gap between short-body 28mm motors and larger 32mm frames, delivering enhanced power density without increasing the mounting footprint. The combination of 28mm diameter and 63mm length makes it an ideal choice for robotics, medical devices, industrial automation, and portable equipment where space is constrained but performance requirements are demanding.
The M28-63-BLDC delivers rated torque from 0.12 to 0.28 Nm depending on winding selection, with peak torque up to 0.55 Nm. No-load speeds range from 2,000 to 11,000 RPM, providing flexibility for applications requiring either high-speed operation or higher torque. The extended 63mm body accommodates a longer stator with more copper windings and stronger rare-earth magnets, resulting in approximately 20–25% higher torque output compared to shorter 28mm motors such as 28×40mm or 28×50mm versions.
Unlike traditional brushed DC motors that require periodic brush replacement and suffer from electrical arcing, the brushless design eliminates mechanical commutation entirely. Typical operational life reaches 15,000+ hours, significantly longer than equivalent brushed motors. The absence of brushes also eliminates electrical arcing, reducing EMI and making the motor suitable for sensitive medical and electronic environments. Low cogging torque design ensures smooth rotation even at very low speeds, critical for precision positioning applications.
Three integrated Hall-effect sensors provide commutation feedback for electronic speed controllers (ESC) and enable precise speed control, direction changes, and smooth starting from zero speed. The Hall sensors allow the motor to start reliably under load and maintain stable operation across a wide speed range. For closed-loop speed or position control, an optional magnetic encoder (up to 1,024 PPR) can be added to the motor rear shaft.
The 63mm body length provides adequate surface area for passive heat dissipation in most applications. Double-shielded ball bearings on both ends ensure low friction and long service life even under continuous duty. Dynamic balancing of the rotor assembly minimizes vibration, important for precision applications such as camera gimbals and medical pumps. The housing can be specified with IP54 protection for dusty or humid environments. Insulation is Class F (155°C) as standard.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (4mm, 5mm, or 6mm), shaft length, and end configurations including flat, keyway, or D-cut. Gearbox attachments (planetary or spur) with reduction ratios from 3:1 to 100:1 are available for torque multiplication. Custom lead wire length and connector terminations (Molex, JST, or custom) are supported. Encoder integration and IP54 sealing are available for volume orders.
Each M28-63-BLDC motor undergoes 100% final inspection including no-load speed, no-load current, Hall sensor functionality, insulation resistance, dielectric strength, and vibration testing. Production follows ISO 9001:2015 quality management processes. RoHS and REACH compliance documentation is available. Sample motors with matched electronic speed controllers are available for engineering evaluation.
-
26mm Metal Brush DC Motor – 10mm Ultra-Thin Body, Flat Design, High Torque Density
The M26-10-MB series is a 26mm diameter metal brush DC motor with an ultra-thin 10mm body length, featuring a flat “pancake” form factor. This motor platform is specifically engineered for applications where axial thickness is the primary constraint but a relatively large diameter is acceptable to achieve the required torque. The 26mm diameter provides a substantial magnet and winding area within just 10mm of body length, delivering useful torque output in an extremely thin package. This makes the M26-10-MB an ideal choice for wearable devices, haptic feedback actuators, compact camera mechanisms, thin smart home devices, and space-constrained rotary actuators.
The M26-10-MB delivers stall torque up to 15 mNm depending on winding selection, with no-load speeds ranging from 2,000 to 10,000 RPM. The motor is available in 3V, 6V, and 12V windings, accommodating battery-powered portable devices as well as low-voltage control systems. The flat rotor design enables rapid acceleration and deceleration despite the short axial length, making this motor suitable for applications requiring fast response.
The metal brush commutation system provides reliable electrical contact and cost-effective performance for intermittent duty cycles. Precious metal brush options are available for applications requiring lower starting voltage and reduced current consumption. The flat construction features a precision-machined housing that maintains tight axial tolerances, ensuring consistent performance and easy integration into thin device assemblies.
The motor weighs approximately 15-20 grams, making it suitable for weight-sensitive portable and wearable applications. Sintered bronze bearings provide low friction and quiet operation. The flat design allows for direct integration into device enclosures with minimal additional mounting hardware, simplifying assembly and reducing overall product thickness.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (2.0mm or 2.5mm), shaft length, and end configurations including flat or D-cut. Custom lead wire length and connector terminations (Molex, JST, or custom) are supported for volume orders. Eccentric weight attachments are available for vibration alert applications. Each M26-10-MB motor undergoes 100% final testing for no-load speed, current, and mechanical runout. The series is RoHS compliant and manufactured under ISO 9001:2015 processes.
-
40mm Brushed DC Motor – 70mm Length, High Power, Heavy-Duty Graphite Brushes
The M40-70-MB series is a 40mm diameter brushed DC motor with a 70mm body length, engineered to deliver high power output and reliable long-term performance in the most demanding applications. This motor platform represents a significant step up in torque and power handling from 36mm frames, offering the substantial output required for power tools, industrial equipment, medical devices, and floor care machinery. The combination of 40mm diameter and 70mm length provides an excellent power-to-size ratio for applications where sustained high torque is essential.
The M40-70-MB delivers rated torque from 0.20 to 0.50 Nm depending on winding selection, with stall torque up to 600 mNm. No-load speeds range from 1,200 to 8,000 RPM, providing flexibility for applications requiring either higher speed or higher torque. The extended 70mm body accommodates a large rotor with more copper windings and a high-energy magnet system, resulting in significantly higher torque output compared to shorter 40mm motors such as 40×50mm or 40×60mm versions.
The graphite/copper brush commutation system offers extended brush life and reliable electrical contact under high current loads, making this motor suitable for continuous-duty and high-cycle applications. The motor is available with either conventional iron-core construction for cost-sensitive applications or coreless (ironless rotor) construction for applications requiring zero cogging torque, low rotor inertia, and smooth operation at any position. The coreless option is particularly valuable for servo and precision positioning applications.
Ball bearings on both motor ends ensure low rotational friction, high radial load capacity, and extended service life. The precision-machined housing provides dimensional stability and efficient heat dissipation, while the dynamically balanced rotor minimizes vibration for smooth, quiet operation. Optional IP54 sealing protects against dust and moisture in demanding environments.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (8mm, 10mm, or 12mm), shaft length, and end configurations including flat, keyway, or D-cut. Planetary gearboxes with reduction ratios from 3:1 to 100:1 are available for torque multiplication, and magnetic or optical encoders can be integrated for closed-loop control. Custom lead wire lengths and connector terminations are supported for volume orders. Each motor undergoes 100% final testing, is RoHS compliant, and is manufactured under ISO 9001:2015 processes.
-
ODM XBD-2059 Brushless DC Motor 3000W 16000RPM 1229.91mNm Torque Explosion-Proof Flange Mount for Home Appliances
- High Torque (1229.91mNm): Provides powerful performance for smooth operation.
- 16000 RPM Speed: Ensures high-speed efficiency in various applications.
- Explosion-Proof Design: Safely operates in hazardous environments.
- Compact Size (40mm): Easy to integrate into small spaces.
- Brushless Motor Technology: Offers long life and low maintenance.
-
36mm Brushed DC Motor – 70mm Length, High Torque, Long-Life Graphite Brushes
The M36-70-MB series is a 36mm diameter brushed DC motor with a 70mm body length, engineered to deliver high torque output and reliable long-term performance in demanding applications. This motor platform bridges the gap between compact 32mm motors and larger 40mm frames, offering a substantial increase in torque and power handling while maintaining a manageable footprint. The combination of 36mm diameter and 70mm length makes it an ideal choice for medical equipment, industrial automation, robotics, power tools, and floor care equipment where sustained power delivery is essential.
The M36-70-MB delivers rated torque from 0.15 to 0.40 Nm depending on winding selection, with stall torque up to 250 mNm. No-load speeds range from 1,500 to 8,000 RPM, providing flexibility for applications requiring either higher speed or higher torque. The extended 70mm body accommodates a longer rotor with more copper windings and a larger magnet system, resulting in significantly higher torque output compared to shorter 36mm motors such as 36×50mm or 36×60mm versions.
The graphite/copper brush commutation system offers extended brush life and reliable electrical contact under high current loads, making this motor suitable for continuous-duty applications. The motor is available with either conventional iron-core construction for cost-sensitive applications or coreless (ironless rotor) construction for applications requiring zero cogging torque, low rotor inertia, and smooth operation at any position. The coreless option is particularly valuable for servo and precision positioning applications.
Ball bearings on both motor ends ensure low rotational friction, high radial load capacity, and extended service life. The precision-machined housing provides dimensional stability and efficient heat dissipation, while the dynamically balanced rotor minimizes vibration for smooth, quiet operation. Optional IP54 sealing protects against dust and moisture in demanding environments.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (5mm, 6mm, or 8mm), shaft length, and end configurations including flat, keyway, or D-cut. Planetary gearboxes with reduction ratios from 3:1 to 100:1 are available for torque multiplication, and magnetic or optical encoders can be integrated for closed-loop control. Custom lead wire lengths and connector terminations are supported for volume orders. Each motor undergoes 100% final testing, is RoHS compliant, and is manufactured under ISO 9001:2015 processes.
-
XBD-1525 High Speed Brushed DC Permanent Magnet Motor 12V 10W for Smart Home & Home Appliance with Customization Support
- High Speed Operation: Achieves up to 11800 rpm for efficient performance.
- Low Noise Construction: Designed with low noise technology for quiet operation.
- Brushless Design: Offers smooth and long-lasting performance without brushes.
- Wide Voltage Range: Operates at 12V for versatile applications.
- High Efficiency: Rated at 79.3%, saving energy and reducing costs.
-
XBD-4270 Permanent Magnet BLDC Motor 12V/24V 8600RPM High Power 100W 18mNm Torque 42mm Frame Explosion-Proof Flange Mount
- High Power Performance: Delivers up to 100W power for efficient smart home applications.
- Precision Torque Control: Maintains 18mNm torque for precise control in various appliances.
- Compact Design: Flange mount design saves space and fits seamlessly into smart home setups.
- Durability: Made with high-quality components ensuring long-lasting performance.
- Energy Efficiency: Achieves IE 1 efficiency rating, reducing energy consumption.
-
22mm Brushed DC Motor – 38mm Length, Coreless Design, High Torque Density
he M22-38-MB series is a 22mm diameter brushed DC motor with a 38mm body length, featuring a coreless (ironless rotor) design. This motor platform is engineered to deliver high torque density, fast dynamic response, and smooth operation in a compact form factor, making it an ideal choice for medical devices, robotics, portable equipment, and precision automation systems where space and performance are both critical.
The M22-38-MB delivers rated torque from 8 to 18 mNm depending on winding selection, with stall torque up to 35 mNm. No-load speeds range from 4,000 to 14,000 RPM, providing flexibility for applications requiring either higher speed or higher torque. The coreless rotor design provides exceptionally linear voltage-speed-torque characteristics, simplifying control system design and enabling precise modeling of motor performance under varying load conditions.
The coreless construction offers several fundamental advantages over conventional iron-core brushed motors. The absence of an iron core eliminates cogging torque, allowing the rotor to stop in any position without preferential alignment—a valuable characteristic for servo and precision positioning applications. Low rotor inertia enables rapid acceleration and deceleration, making this motor particularly suitable for dynamic applications requiring fast response times. The ironless design also reduces winding inductance, minimizing sparking between the brushes and commutator, which extends motor life and reduces electromagnetic interference (EMI).
The carbon brush commutation system provides reliable electrical contact with extended brush life. For applications requiring lower starting voltage and reduced current consumption, precious metal brush options are available. The motor is available in 12V and 24V windings, accommodating a range of power supply requirements.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (2.5mm, 3mm, or 4mm), shaft length, and end configurations including flat or D-cut. Gearbox attachments (planetary or spur) with reduction ratios from 3:1 to 500:1 are available for torque multiplication. For applications requiring precise speed and position control, an optional magnetic encoder can be integrated. Custom lead wire length and connector terminations (Molex, JST, or custom) are supported for volume orders.
Each M22-38-MB motor undergoes 100% final testing for no-load speed, current, and mechanical runout. The series is RoHS compliant and manufactured under ISO 9001:2015 processes. Sample motors are available for engineering evaluation.
-
32mm Brushless DC Motor – 60mm Length, Compact High-Torque BLDC with Hall Sensors
The M32-60-BLDC series is a 32mm diameter brushless DC motor with a 60mm body length, designed for applications requiring a compact yet powerful drive solution. This motor platform delivers a significant step up in torque compared to 28mm motors while maintaining a smaller footprint than 36mm and 40mm frames. The combination of 32mm diameter and 60mm length provides an excellent power-to-size ratio for robotics, medical equipment, industrial automation, and consumer appliances.
The M32-60-BLDC delivers rated torque from 0.15 to 0.35 Nm with peak torque up to 0.9 Nm, depending on winding selection. No-load speeds range from 2,000 to 10,000 RPM, allowing designers to optimize for either high-speed or high-torque applications. The brushless design provides high efficiency (up to 86%), reducing heat generation and improving energy economy compared to brushed alternatives.
Unlike traditional brushed DC motors that require periodic brush replacement and suffer from electrical arcing, the brushless design eliminates mechanical commutation entirely. Typical operational life reaches 15,000+ hours—three times longer than equivalent brushed motors. The absence of brushes also eliminates electrical arcing, reducing EMI and making the motor suitable for sensitive medical and electronic environments. Low cogging torque design ensures smooth rotation even at very low speeds, critical for precision positioning applications.
Three integrated Hall-effect sensors provide commutation feedback for electronic speed controllers (ESC) and enable precise speed control, direction changes, and smooth starting from zero speed. The Hall sensors allow the motor to start reliably under load and maintain stable operation across a wide speed range. For closed-loop speed or position control, an optional magnetic or optical encoder (up to 1,024 PPR) can be added to the motor rear shaft.
The 60mm body length provides adequate surface area for passive heat dissipation in most applications. Double-shielded ball bearings on both ends ensure low friction and long service life even under continuous duty. Dynamic balancing of the rotor assembly minimizes vibration, important for precision applications. The housing can be specified with IP54 protection for demanding environments. Insulation is Class F (155°C) as standard.
OEM customers can specify winding voltage and speed/torque characteristics, shaft diameter (5mm, 6mm, or 8mm), shaft length, and end configurations including flat, keyway, or D-cut. Gearbox attachments (planetary or spur) with reduction ratios from 3:1 to 100:1 are available for torque multiplication. Custom lead wire length and connector terminations (Molex, JST, AMP, or custom) are supported. Encoder integration and IP54 sealing are available for volume orders.
Each M32-60-BLDC motor undergoes 100% final inspection including no-load speed, no-load current, Hall sensor functionality, insulation resistance, dielectric strength, and vibration testing. Production follows ISO 9001:2015 quality management processes. RoHS and REACH compliance documentation is available. Sample motors with matched electronic speed controllers are available for engineering evaluation.
-
40mm Brushless DC Motor – 88mm Length, 170W High Power Density, Slotless Design
The M40-88-BLDC series is a 40mm diameter brushless DC motor with an extended 88mm body length, engineered for applications requiring high power density, high-speed operation, and low vibration. This motor platform delivers up to 170W of output power in a compact 40mm frame, making it an ideal choice for medical pumps, aerospace actuators, precision industrial equipment, and professional power tools where space and performance are both critical.
The M40-88-BLDC delivers rated torque from 0.15 to 0.35 Nm depending on winding selection, with peak torque up to 1.0 Nm. No-load speeds range from 3,000 to 10,000 RPM, providing flexibility for applications requiring either high-speed operation or higher torque. The extended 88mm body accommodates a longer stator with more copper windings and stronger rare-earth magnets, resulting in significantly higher torque and power output compared to shorter 40mm motors.
The motor features a slotless (coreless) stator design, which eliminates the iron teeth found in conventional brushless motors. This construction provides exceptionally low cogging torque and smooth rotation even at very low speeds, critical for precision positioning applications. The absence of slot-induced magnetic reluctance variations also reduces vibration and acoustic noise, making this motor suitable for noise-sensitive environments and high-speed spindle applications.
Unlike traditional brushed DC motors that require periodic brush replacement and suffer from electrical arcing, the brushless design eliminates mechanical commutation entirely. Typical operational life reaches 20,000+ hours under normal operating conditions. The absence of brushes also eliminates electrical arcing, reducing EMI and making the motor suitable for sensitive medical and electronic environments.
Three integrated Hall-effect sensors provide commutation feedback to the electronic speed controller, enabling smooth startup, accurate speed regulation, and instantaneous direction changes. Double-shielded ball bearings at both ends ensure low rotational friction and long service life under radial and axial loads. The housing can be specified with IP54 or IP65 protection for demanding environments.
OEM customers can specify winding configurations, shaft diameter (6mm, 8mm, or 10mm), shaft length, and end configurations including flat, keyway, D-cut, or spline. Gearbox attachments with ratios from 3:1 to 100:1 are available for torque multiplication. Sample motors with matched electronic speed controllers are available for engineering evaluation.
