XBD-3571 coreless brushed dc motor
Product Introduction
XBD-3571 coreless brushed dc motor will offer a good specification with continuous high power, speed and torque to customer’s equipment and lead high precise, reliable control, lower vibration and noise which can provide a good user experience.
We can make the customized shaft and holes at the front cover. This type of 3571 Coreless DC Motor can completely replace the DC Motor from Europe. Most of important, we can customize motor parameters for our customers which will give full play to product advantages to short the delivery time and save the cost for our customer.
Features
● High density ironless cylindrical winding
● No magnet cogging
● Low mass inertia
● Rapid reaction
● Low inductance
● Low electromagnetic interference
● No iron loss, high efficiency, long motor life
● Fast speed, low noise
Application
Sinbad coreless motor have a wide range of application such as robots, drones, medical equipment, automobiles, information and communications, power tools, beauty equipment, precision instruments and military industry.
Parameters
| Motor model 3571 | ||||||
| At nominal | ||||||
| Nominal voltage | V |
12 |
15 |
18 |
24 |
48 |
| Nominal speed | rpm |
6697 |
6497 |
6039 |
7229 |
6118 |
| Nominal current | A |
7.47 |
4.23 |
3.23 |
4.22 |
2.17 |
| Nominal torque | mNm |
110.98 |
81.76 |
82.35 |
117.62 |
125.69 |
|
Free load |
||||||
| No-load speed | rpm |
7400 |
7100 |
6600 |
7900 |
7600 |
| No-load current | mA |
280 |
160 |
150 |
150 |
80 |
|
At max efficiency |
||||||
| Max efficiency | % |
88.2 |
88.8 |
87.8 |
89.1 |
88.0 |
| Speed | rpm |
6993 |
6710 |
6237 |
7466 |
7144 |
| Current | A |
4.445 |
2.791 |
2.204 |
2.872 |
1.335 |
| Torque | mNm |
64.3 |
52.9 |
53.3 |
76.1 |
75.4 |
|
At max output power |
||||||
| Max output power | W |
226.3 |
178.8 |
167.4 |
286.2 |
250.0 |
| Speed | rpm |
3700 |
3550 |
3300 |
3950 |
3800 |
| Current | A |
38.1 |
24.1 |
18.8 |
24.1 |
11 |
| Torque | mNm |
584.1 |
481.0 |
484.4 |
691.9 |
628.5 |
|
At stall |
||||||
| Stall current | A |
76.00 |
48.00 |
37.50 |
48.00 |
21.00 |
| Stall torque | mNm |
1168.2 |
961.9 |
968.8 |
1383.8 |
1256.9 |
|
Motor constants |
||||||
| Terminal resistance | Ω |
0.16 |
0.31 |
0.48 |
0.50 |
2.3 |
| Terminal inductance | mH |
0.050 |
0.120 |
0.170 |
0.190 |
0.8 |
| Torque constant | mNm/A |
15.43 |
20.11 |
25.94 |
28.92 |
60.1 |
| Speed constant | rpm/V |
616.7 |
473.3 |
366.7 |
329.2 |
158.3 |
| Speed/Torque constant | rpm/mNm |
6.3 |
7.4 |
6.8 |
5.7 |
6.0 |
| Mechanical time constant | ms |
5.31 |
5.87 |
5.43 |
4.48 |
5.06 |
| Rotor inertia | g·cm² |
79.98 |
76.01 |
76.06 |
79.50 |
79.98 |
| Number of pole pairs 1 | ||||||
| Number of phase 13 | ||||||
| Weight of motor | g | 360 | ||||
| Typical noise level | dB | ≤48 | ||||
